Course Code            : HCCC01

Course Name           : AutoCAD 2017

Duration                  : 2 Months

Eligibility                 : Diploma / BE/ ME (MECH) / ITI / +2 / Equivalent

Syllabus:

• Introduction to Engineering Drawings
  Projections (First & Third angle)
  Views (Orthographic, Isometric & Perspective)
  Introduction to AutoCAD
  Co-ordinate systems
• Drawing settings – Units, Limits, UCSIcon
  Drawing simple sketches using Line, Circle, Arc, Ellipse, Polygon, Rectangle, Drafting Setting
• Editing commands – Erase, Undo, Redo, Move, Copy, Rotate, Array, Mirror
  File Management - New, Qnew, Open, Save, Save as, Close, Exit, Quit
  Mini Project 1 – Orthographic Views
• Editing commands – Fillet, Chamfer, Scale, Stretch, Offset, Break, Trim, Extend
• Hatches, Hatch Edit
• Object Selection Methods
  Select, Qselect
  Annotations - Text, Style, Ddedit, Mtext, Scaletext, Spell, Table, Tabledit
  Object Properties - Color, Linetype, Ltscale, Lineweight, Properties, Matchprop
• Dimension - Linear, Aligned, Radius, Diameter, Center Mark, Angle, Arc length, Continuous, Baseline, Dimension Space, Dimension Break, Jogged radius, Oblique, Align Text, Mleader, Qleader
• Isometric view,Iso plane Mini project 2 - Isometric views
• 3D Introduction
• Region, Explode, Extrude, Revolve, Union, Subtract, Slice, Thicken
• Modeling Tools : Solid Primitives
  Box, Wedge, Cylinder, Cone, Sphere, Torus,
• 3D move, 3D rotate, 3D Array, 3D Mirror, fillet Edge, Chamfer Edge
• Polysolid, Sweep, Helix, Loft, Print setup
• Layer Management
  Adding / Removing Layers
  Layer Status
• Speed test
• Subject of cad
• Mini Project 1 (2D)
• Mini Project 2 (Isometric)
• Mini Project 3 (3D)
• Final Project
